튜브
밸브

밸브

  • TR 13
    TR 15

  • TR 218A
    TR 220A

  • TR 75A TR 175A
    TR 76A TR 177A
    TR 77A TR 179A
    TR 78A

  • TR 150
    TR 135
    TR 150 CW
    TR 135 CW

  • JS 244A

  • JS 89
    JS 2

  • V3-SERIES

  • V3-06-SERIES

  • V3-04-SERIES

  • TRJ 4000
    TUBE TYPE SPUD
    ASSEMBLY SP 4000

  • TRJ 1175C

구성

Group Size Bias

No
크기
밸브
수량/상자
적용 가능한 크기
7
ER-10
TR13
35
500-10 / 3.5-10 4.0, 4.5, 5.0-10 / 135/145-10
8
ER-10
TR15
35
500-10 / 3.5-10 4.0, 4.5, 5.0-10 / 135/145-10
11
DR-12
TR13
40
400-12 / 450-12 / 125/135-12
12
ER-12
TR13
35
500/550-12 / 145/155/135-12 155/450/500-12 / 4.5/4.8/530-12
13
FR-12
TR13
35
155/165/175-12 / 6.0-12 / 6.2-12
14
ER-13
TR13
35
135/145/155-13 / 5.0, 5.2, 5.5-13
15
FR-13
TR13
33
175/185/70-13 / 165-13 / 560-13 / 155/165-13 / 6.0, 5.6, 5.9-13
16
GR-13
TR13
30
175/185-13 / 185/70-13 / 7.0-12/13
17
ER-14
TR13
35
135/145-14 / 5.0/5.2-14
18
FR-14
TR13
30
155/165-14 / 165/175-14
20
GR-14
TR13
25
185/195/205-14, 6.5/7.0-14, 650/645-14
21
KR-14
TR13
25
7.50/8.25-14, 195/205-14, 9.5L-14,15
22
MR-14
TR75A
20
9.5-14 / 215/225, 225/235-14, 235/70-14 / H78-14
23
DR-15
TR13
30
125/135/145X15 / 4.0/4.4-15
24
FR-15
TR13
25
600-15, 650-15 / 155/165-15, 5.7, 6.0, 6.45-15 / 6.80/7.15-15
27
GR-15
TR13
25
6.50/7.00-15,7.35/6.75-15,175/185/195/170/180-15
28
KR-15
TR13
20
195/205/215-15 / 215/70-15 / G78-15 / 7.0, 7.1, 7.6-15 / 9.5L-15
30
MR-15
TR13
20
235/245-15 / 225, 235, 265/70-15, 250/300-15 / 215/225-15 / 8.2, 8.4, 9.15-15
31
G60R15
TR13
25
185/195/65-15, 195/205/60-15
42
KR-16
TR75A
16
7.00/7.50-16 / 205/215-16 / 8-16, 7/8-17.5

Tire Flaps

Tube Size
Flap Size
Pcs / Box
6.00-9
9-4.8
30
6.50-10
10-6.0
30
7.00-12
12-5.7
30
6.00-15, 6.50-15
15-6.4
20
6.50-15, 7.00-15, 7.50-15, 8.25-15,
200/700-15, 195R15,
7.00R15, 7.50R15, 8.25R15, 15L
15-7.05
20
250/8.15-15, 8.15-15, 9.00-15,
10.00-15, 300-15
15-7.7
17
6.50-16, 7.00-16, 7.50-16, 8.25-16,
L-16, 6.50R16, 7.00R16,
7.50R16, 205R16
16-6.9
20
9.00-16
16-7.3
10
7.00-20, 7.50-20, 8.25-20,
9.00-20, 9.00R20
20-7.5
9
10.00R20, 11.00R20, 8.5R-20
20-8.5
8
10.00-20, 11.00-20
20-8.5
8
13.00-20, 14.00-20
20-10
6
10.00-22, 11.00-22, 10.00R22, 11.00R22
22-8.3
7
11.00-24, 12.00-24, 13.00-24,
11.00R24, 12.00R24
24-8.5
6
14.00-24, 16.00-24, 16.00-25
15.5-25
25-10.5
4
17.5-25
25-14.5
2
20.5-25, 23.5-25
25-20
2
7.50-18, 7.50R18
18-6.97
10
12.00-20, 12.00R20, 11.00/12.00-20
20-9.1
6
